Prorack Whispbar Q20 - Page 13

Whispbar Track System
EN
Q20
● Thread the nut over the T-bolt by hand.
● Repeat for all four positions.
● Use the 3mm (1/8") Hex Key to hold the T-
bolt in a stationary position and ensure the
T-bolt has correct engagement.
● Using the 10mm (3/8") spanner supplied,
tighten the nut to 5Nm (3.7 ft lb).
● Tighten with provided 10mm (3/8")
spanner.
13
