Whispbar Track System
EN
Q20
● If the position of the roof racks need to be
adjusted along the tracks, use the 3mm
(1/8") hex key to hold the T-bolt stationary,
and using the 10mm (3/8") spanner
supplied loosen both of the nuts slightly on
all the mounting points to be adjusted.
● Adjust the position of the mounting points
along the tracks as required.
● Use the 3mm (1/8") Hex Key to hold the T-
bolt in a stationary position and ensure the
T-bolt has correct engagement.
● Using the 10mm (3/8") spanner supplied,
tighten the nut to 5Nm (3.7 ft lb).
● Use keys to remove covers.
