OPERATION AND CONTROLLER INSTRUCTIONSFEATURES & TECHNICAL DATA
FEATURES
- Electronic EMS pulse muscle Stimulator with 6 intensity levels.
- 2 electrode plates plus 2pcs external electrode pads
- Optional Heat Therapy (2 heating levels)
- Built in rechargeable Lithium battery (USB cable charging)
- Adjustable drawcord with cordlock to  t neck size.
- Soft  eece cozy cloth, Removable and Washable
TECHNICAL DATA
Measurements: 11.8*11*6.3inch
Weight: 1.38lbs
Battery: 3.7V,1000mAh.
Nominal power: Max. 3 Watt
Battery Full Charging: 2.5-3 hours
Battery Max. Runtime: 3hours
Default Automatic Runtime: 15 minutes
2 electrode pads
Removeable &
washable cover
Control
panel
Adjustable
drawcord
electrode plate
USB charging
cable
connection cable
OPERATION AND CONTROLLER
INSTRUCTIONS
Charging Indicator
While charging  Flash Red light
Fully charged  Green light
Electrotherapy Indicator EMS
The intensity of electrotherapy from low to high is displayed in 6 colours:
dark green  green dark yellow yellowdark red red
Indicator of
vibration massage
EMS Indicator of Electrotherapy
USB-charging-port
EMS
Increase intensity (+)
Decrease intensity (-)
Port for
external electrode pads
Heat Indicator
Charging indicator
+
Electrotherapy
intensity indicator
EMS
Heat button
Press 1x  Low
Press 2x  High
Press 3x  Heat o
On-/o -button &
program control (1-4):
Press 1x  Vibration massage + EMS-Mode 1
Press 2x  EMS-Mode 1
Press 3x  EMS-Mode 2
Press 4x  Vibration massage
EMS-Tip:
The electrical stimu-
lation becomes more
comfortable if you use
an electrode gel or if
you moisten the skin
slightly.
GREEN  EMS - Mode 1
RED  EMS - Mode 2
YELLOW  Low
RED  High
GREEN  „ON“
Press and hold on 2-3 seconds to turn o the device.
+-
