Tone mode
9 adjustable tone
Compatible connectors
RJ45(8 pin)、RJ11(6 pin)、BNC、
USB、IEEE 1394
Continuity test LCD (SHORT)
Transmitter
Max. signal voltage 1.5Vp-p
Function selection 3 function buttons ＆ 1 power switch
Function and faults LCD
display
LCD display (wire map；tone；short；
no adapter；UTP；STP；low battery)
Cable map indication LCD (#1~#8)
Shielded indication LCD (#9)
Voltage protection AC 60V/ DC 42V
Low battery display LCD (6.5V)
Battery type
DC 9.0VNEDA 1604/ 6F22 DC9V ×1)
(Alkaline battery recommended)
Dimension (LxWxD) 185X80X32mm
Receiver
Frequency 225kHz
The max. working current ≦70mA
Ear jack 1
LED illumination 2 LEDs
Battery type
DC 9.0VNEDA 1604/ 6F22 DC9V ×1)
(Alkaline battery recommended)
Dimension (LxWxD) 218X46X29mm
Remote unit
Compatible connectors
RJ-45(8 pin)、RJ-11(6 pin)、BNC、
USB、IEEE 1394
Dimension (LxWxD) 107X30X24mm
