Once the PFM-711B Field Meter and CPM-720B Charge Plate are assembled, the PCS-730B
Electrostatic Charger will apply a defined electrostatic voltage to the CPM-720B plate.
PCS-730B Pushbuttons
The PCS-730B has two (2) button switches to charge the plate assembly:
Applies a positive charge to the CPM-720B charge plate
assembly to approximately + 1.25kV ±5%.
Applies a negative charge to the CPM-720B charge plate
assembly to approximately – 1.25kV ±5%.
Table 4. PCS-730B Pushbuttons
Battery Installation
The PCS-730B uses one (1) 9 VDC alkaline battery (included), which provides an approximate life of XX
hours. To install or replace the battery, follow this procedure (Figure 6):
1. On the back of the meter, there’s a battery compartment. Carefully press down the cover
using its grooves.
2. Remove the old battery carefully (if present).
3. Firmly nap the battery terminals to the appropriate connectors. Make certain of the polarity.
4. Carefully reclose the battery compartment cover.
