Prostat PRS-812 User Manual

14
Rev. C / January 2012
PRS-812 Resistance Meter
 Displayed when  buon is pushed second me while in  mode.
Number displayed when  is indicated is the Minimum data value in
Memory Register.
 Displayed when  buon is pushed a third me (sequenally) in 
mode. Number displayed when  is indicated is the Maximum data value
in Memory Register.
 Displayed when  buon is pushed the fourth me (sequenally) in
 mode. Number displayed when  is indicated is the Average of all
data values in Memory Register that are less than 2.0x10
14
ohms. (OL’s are
not included in averaging calculaon.)
 Either the  buon must be depressed a h me or 
pressed to return the system to its operaonal, measurement mode.
 Indicates that the Memory Register is  and is Recording data each me
the  buon is depressed aer a  measurement.
 Ohms: Indicates measurement between 0.1 and 999 ohms
 Indicates measurements from 1,000 (1.0x10
3
) to 990,000 (9.9x10
5
) ohms
 Indicates measurements from 1,000,000 (1.0x10
6
) to 999,000,000 (9.9x10
8
)
ohms
 Indicates measurements from 1,000,000,000 (1.0x10
9
) to 999,000,000,000
(9.9x10
10
) ohms
 Indicates measurements from 1,000,000,000,000 (1.0x10
12
) to
200,000,000,000,000 (2.0x10
14
) ohms
 Indicates <10, 10 or 100 volts being applied as the test voltage.
 Indicates measurement is complete at the end of a  cycle. Holds data
point in display unl instrument is  or  is depressed.
Baery indicaon for low voltage


 Power terminal for supplying Test Voltage to xture or material under test.

 Sensing Terminal for measurement of current (I) through xture or material
under test.
