6
Rev. C / January 2012
PRS-812 Resistance Meter
-
AUTOMATIC 1
[Default]
1.0EXX
IND Ω - TΩ
AUTO AUTO. AUTO.
AUTOMATIC RESISTANCE RANGE,
TEST VOLTS, ELECTRIFICATION,
DISPLAY HOLD
AUTOMATIC 2
OHMS
Ω - TΩ
AUTO AUTO. AUTO.
MANUAL 1
1.0EXX
IND Ω - TΩ
MANUAL MAN
MAN. or
AUTO
TEST ONLY; NO DISPLAY HOLD
UL= UNDER DECADE LEVEL
OL= OVER DECADE LEVEL
MANUAL 2
OHMS
Ω - TΩ
MANUAL MAN
MAN. or
AUTO
MANUAL/
AUTOMATIC 1
1.0EXX
IND Ω - TΩ
AUTO &
MANUAL
MAN. Start
AUTO
Run
AUTO.
MANUAL SETUP STARTING
DECADE, AUTO ADJUST RANGE,
TEST VOLTS, ELECTRIFICATION
DISPLAY HOLD
MANUAL/
AUTOMATIC 2
OHMS
Ω - TΩ
AUTO &
MANUAL
MAN. Start
AUTO
Run
AUTO.
#1 AUTOMATIC: RESISTANCE RANGES IN AUTO 0.1Ω TO <2.0E+12Ω as follows
@<10V: 0.1 TO <1.0E+04Ω (0.1Ω - < 10KΩ)
@ 10V: 1.0E+04 TO <1.0E+06Ω (10KΩ - < 1MΩ)
@100V: 1.0E+06 TO <2.0E+12Ω (1MΩ - <200TΩ)
#2 MANUAL: RESISTANCE RANGES IN MAN 0.1Ω TO <2.0E+12Ω as follows
@<10V: 0.1 TO <1.0E+05Ω (0.1Ω - <100KΩ)
@ 10V: 1.0E+03 TO <1.0E+09Ω (1KΩ - <1GΩ)
@100V: 2.0E+05 TO <2.0E+12Ω (200KΩ - < 200TΩ)
#3 AUTO-MANUAL: (Same as AUTOMATIC)
RESISTANCE RANGES IN AUTO-MANUAL 0.1Ω TO <2.0E+12Ω as follows
@<10V: 0.1 TO <1.0E+04Ω (0.1Ω - < 10KΩ)
@ 10V: 1.0E+04 TO <1.0E+06Ω (10KΩ - < 1MΩ)
@100V: 1.0E+06 TO <2.0E+12Ω (1MΩ - <200TΩ)
2. The PRS-812 provides three separate test voltages for resistance measurements as indicated in
the table, above:
<10 Volts
10 Volts
100 Volts
In and modes the instrument automacally controls volt-
age and resistance range based on resistance characteriscs of materials being measured. In
the mode the operator may select test voltage and and resistance range. Note that
the most ecient mode of operaon in for maximum baery life.
