ILLUS. NO DESCRIPTION PART NO
1 HEIGHT ADJUSTER LEVER 120020
2 BELT TENSIONER LEVER 120152
3 HEIGHT ADJUSTER ARM 120201
4 HEIGHT ADJUSTER LEVER PIVOT BOLT 120212
5 PIVOT SLEEVE 120211
6 M10 CASTLE NUT 2641303
7 HEIGHT ADJUSTER CLIP 120203
8 HEIGHT ADJUSTMENT PIN 120202
9 HEIGHT ADJUSTER RUBBERS (SET) 120510
10 HEIGHT ADJUSTER SUPPORT ANGLE 120511
11 SIDE ARM 120210
12 SIDE ARM BUSH 120213
13 M10x40 CAP SCREW + FLAT WASHER + SPRING WASHER + NYLOC NUT STANDARD
14 SOD CUTTER BLADE 120174
15 5/8" UNF CASTLE NUT 2641300
16 SIDE ARM GREASE COVER 120590
17 M3x50 SPLIT PIN STANDARD
18 M16 SPRING WASHER STANDARD
19 M10x70 SET SCREW + M10 FLAT WASHER + 2xM10 NUTS STANDARD
20 HEIGHT ADJUSTER REINFORCING PLATE 120700
PAGE 8
