ILLUS. NO DESCRIPTION PART NO
1 ENGINE PULLEY TENSIONER COMPLETE ASSEMBLY (LONG) 120181
2 ENGINE PULLEY TENSIONER SPRING 120560
3 SPRING ROD 120179
4 1/8" x 1" SELLOCK PIN STANDARD
5 FRONT WHEEL PULLEY TENSIONER COMPLETE ASSEMBLY (SHORT) 120180
6 TENSIONER WASHER 120575
7 FRONT WHEEL PULLEY TENSIONER SPRING 120562
8 6304 JOCKEY PULLEY BEARING 1123423
9 52mm INTERNAL CIRCLIP 1502520
10 JOCKEY PULLEY 120182
11 M10x40 COUNTERSUNK SCREW + M10 NYLOC NUT STANDARD
12 FRONT WHEEL BELT TENSIONER SIDE PLATES (EACH) 120185.1
13 FRONT WHEEL BELT TENSIONER BEARING SHAFT 120185.4
14 FRONT WHEEL BELT TENSIONER PIVOT BAR 120550
15 FRONT WHEEL BELT TENSIONER STUD 120185.2
16 SWIVEL CASTOR WHEEL 6361800
17 M10x30 SET SCREW + FLAT WASHER + SPRING WASHER + NUT STANDARD
18 JOCKEY PULLEY BRACKET 120021
19 ADJUSTER SCREW 120149
20 JOCKEY PULLEY BRACKET BUSH 3111030
21 1/2" UNF NYLOC NUT STANDARD
22 JOCKEY PULLEY PIVOT BOLT 120190
23 5/8" UNF NYLOC NUT + M16 FLAT WASHER STANDARD
PAGE 12
