PROTEA BG 760 - Page 10

6
2
3
6
7
4
5
1
SECTION 1
REFER FIGURE 1
ILLUS.
NO DESCRIPTION PART NO.
Side Frame Assy. LH
Side Frame L.H. (Click System)
Side Frame Assy. RH
Side Frame R.H. (Click System)
Scraper Trough Assy.
Trough Cover Plate Assy.
Trough Pivot Bar
Washer M10 Spring Washer
Nut M10
1
1
2
2
3
4
5
6
7
305795
305800
305779
305782
305664
305728
305701
Standard
Standard
FIGURE 1
