PROTEA BG 760 - Page 17

1 Clutch Housing Side 302068
2 Clutch Housing Body Assy 302092
3 M5 x 10 Set Screw Standard
4 Clutch Ramp Moveable 305509
5 M6 x 80 Hex Bolt Standard
6 Washer M6 Standard
7 Nut M6 Standard
8 M8 Spring Washer Standard
9 5/16 UNF Nut Standard
10 Clutch Ramp Fixed 302340
11 Clutch Ramp Stop 302359
12 M5 x 12 Cap Screw Standard
13 Washer 1/4 S/Proof 3711163
14 Clutch Ramp Spring 302375
15 Seat Block Clamp 302084
16 Housing Side Seat Block 302076
17 Washer M8 Standard
18 Nut M8 Standard
19 Drum Clutch Gear 302252
20 Bush (Drum Clutch Gear) 172216
21 Drum Clutch Shaft 302279
22 Clutch Shaft Thrust Race 3531020
23 Washer 1/2 Bright Standard
24 Nut 1/2 UNF Standard
25 Clutch Release Yoke 302308
26 Clutch Yoke Pillar 302316
27 Washer M10 Clutch Yoke Pillar (Not Shown) Standard
28 Nut 3/8 UNF - Clutch Yoke Pillar (Not Shown) Standard
29 Yoke Pin 302332
30 Pin Retainer 1/4 Circlip Standard
31 Trunnion Pivot Screw 302324
32 Clutch Plate Assy (Stud Side) 301286
33 Clutch Spring Stud 302236
34 Clutch Spring 302244
35 Clutch Release Trunnion 302287
36 Clutch Plate Lining 301276
37 1/4 BSW Nylock Nut Standard
38 M5 x 10 Panhead Screw Standard
39 Clutch Plate Assy (Sprocket Side) 301252
40 Clutch Plate Bush 3111271
41 Drum Clutch Sprocket 14T 302228
42 Clutch Shaft Washer 11/8 x 1/2 (Not Shown) 3659011
43 Clutch Release Thrust Race 3531026
44 Release Thrust Washer 302295
45 Circlip 1 1/2 EXT Standard
46 Felt Oil Strip 302210
47 Clutch Housing Cover Assy. 302130
48 Clutch Shaft Support Bracket 302121
49 Bolt 1" x 5/16 UNF Standard
50 Washer M8 Standard
51 Cover Holding Bracket Assy. 302172
52 Inter. Cluster Gear 302412
53 Bush 5/8 x 3/4 x 3/4 3111030
54 Circlip 5/8 EXT. Standard
55 Intermediate Gear Shaft 302420
56 Washer 5/8 Bright Standard
57 Washer M11 Standard
58 Housing Cover Screw 302164
59 Nut 7/16 UNF Standard
60 Clutch Housing Side Cover 302201
13
ILLUS.
NO.
PART
NO.
DESCRIPTION
FIG 5
