2 SPEED GEARBOX:
The “Protea” Gearbox has 3 positions,
1. Left - SLOW
2. Centre - NEUTRAL
3. Right - FAST
If the gearbox and lever is in the slow (1) or fast (2) position, and the mower does not move, adjust as follows:
Release 4 x M8 bolts and reposition selector grid (see item 5 – page 1) until gear lever engages gearbox in slow
and fast position.
2 SPEED GEARBOX:
When gear lever Item 2 9refer page 4) is in neutral position (N) the mower must remain stationary, although
clutch lever 7 (Ref. Page 4) is fully engaged. If the mower is moving adjust as follows;
1. By releasing 4 x M8 bolts and reposition selector grid (Item3-Page4)
OR
2. By adding or removing spacer washer Item 16 (Page 4) to get gear lever 2 in central position (N).
