ITEM ORDER# DESCRIPTION QUANTITY
1 101781 Blind Twist Cap Assembly 1 each
2 101499 Twist Cap for 1
1
/2
" Cuff 1 each
3 102784 Dome Filter w/ Foam Media 1 each
4 101949 Foam Filter Media for Dome Filter 1 each
102761 High Filtration Disc (Optional) 2/pack
5 100564 Cloth Filter 1 each
6 100431 496 sq. in. Intercept Micro Filter™ 10/pack
7 101705 3' to 1' Stretch Hose w/Cuffs 1
1
/2" 1 each
8 102878 Waist Belt w/Velcro® 1 set
103025 Retrofit Set: Waist Belt and Monostrap 1 set
9 101274 Waist Belt Connection Set: 4 Screws, 6 Washers, 2 Stand-offs 1 set
10 102879 Monostrap Assembly 1 each
11 101272 Step Cap Screw Kit: 4 Screws 1 set
12 101753 Deflector Shroud Assembly w/2 Screws 1 each
13 103236 Motor Seal 1 each
14 101189 802 Watt Motor/Fan (120 V) w/Crimps 1 each
15 102988 Carbon Brush Set for 802 Watt Motor 1 set
16 103043 Fan & Brush Cover Kit 1 each
17 101271 Motor Mount Screw Kit: 5 Screws, 4 Washers, 1 Nut 1 each
18 100950 Director Plate 1 each
19 101713 Power Cord Assembly (18" 16/3) Complete w/Strain Relief
w/Locknut and Washer 1 set
20 100743 Double Pole On/Off Switch 1 each
21 101228 Front Sound Foam Baffle 1 each
22 101229 Rear Sound Foam Baffle 1 each
23 105045 Step Cap 1 each
24 105042 Receptacle Replacement Kit w/Att. Front Sound Foam,
2 Rivets, 2 Washers, 1 Receptacle, 1 Connector & Wire
Assembly, 2 Female Crimps 1 set
25 101536 Replacement Fixed Hose Cuff (Black) 1
1
/2" 1 each
26 100694 Replacement Swivel Cuff (Black) 1
1
/2" 1 each
101678 50' Extension Cord (Not shown) 1 each
ALPINE
®
PARTS LIST
Owner’s Manual
ALPINE
®
ASSEMBLY
Owner’s Manual
