16
Cable Holders
(pg. 4)
Sensitivity Control Switch
(pg. 6)
LED On/Off Switch
(pg. 5)
Removable Terminal Strip
(pg. 4)
PRINTED CIRCUIT BOARD PIRAMID XL2
Enhanced Bird/Animal
Immunity Control Switch
(pg. 7-8)
Tamper Switch
(pg. 5)
Voltage OK LED
(pg. 5)
Range Control Switch
(pg. 6)
Spring Contact
Housing Ground
(pg. 4)
15
