Proteco RF 36 - Page 3

12V dc
24V ac
24V dc
1 2
3 4
7 8
9
10 11
12
RF 36
Rx
+AC
+AC -0AC+AC -0AC
- 0AC
Tx
+AC -0AC+AC -0AC
+AC
- 0AC
Terminal Block 2a Terminal Block 2b
Rx
+AC
+AC -0AC+AC -0AC
- 0AC
Tx
+AC -0AC+AC -0AC
+AC
- 0AC
WIRING SCHEME USED FOR INSTALLING TWO PAIRS OF SAFETY
PHOTOCELLS IN THE CLOSING PHASE
If you need to connect the two pairs of cells in OPENING phase instead of closing
phase, simply move the wire that is shown connected to terminal 3 into terminal 4
12V dc
24V dc
24V ac
