DISMANTLING
1. Loosen all velcro straps on the roof panel.
2. Press the red push button release below the plastic gliders
on each leg. This releases the pressure on the roof frame.
3. Release the push button spring and retract the legs.
4. Grasp the frame above the middle pivot point on the roof
proles, lift slightly and push together again by stepping
forward but do not close completely to prevent jamming.
5. Push the frame together completely at the upper corners.
6. The frame can now be stowed in the mobile transport bag
together with the roof, which should be smoothed out á
little beforehand. To do this, open the bag completely and
place it sideways over the frame with the fabric roof. Pull
the bag down well. Then close the zip and the buckle.
Push button release
8
