To replace the cable, ask an authorized
service centre.
Any time you start working with the vacuum
cleaner, first check integrity of the filter.
Any time you start working with the vacuum
cleaner, check the condition of the hose: the
opening must be free.
Do not suck in any inflammable liquids, e.g.
petrol, diluents, etc. Danger of explosion!
Before you start wet hovering, remove the
filtering bag / liquidation bag.
Supply cable must not be under tensile load
or laid on/through sharp edges, and cannot
be passed over by any machine or damaged
mechanically in any other way.
Check the supply cable regularly. If dama-
ged, do not use the vacuum cleaner. At
replacement of extension cables, supply
cable, etc., protective class, type of protec-
tion or mechanical strength must be kept the
same.
Always use the supply cable recommended
by the manufacturer (H05 RR-F /
H07 RN-F).
With respect to protection at work, preven-
tion against electric accident, and guarantee
of the protective class, the above repair jobs
must be performed by a professional service
centre, authorized to deal with repairs of this
type. Kindly contact the authorized service
centre PROTOOL.
While performing any repair or maintenance
work, disconnect the supply cable.
The electric outlet on the vacuum cleaner
may be used only for the purpose as
described in the instruction manual.
Protect the plug, electric outlet and
connecting parts of the supply cables
against any contact with water.
Use original spare parts only.
Protect the upper part of the vacuum cleaner
against water. Danger of short-circuits!
WARNING! If foam/liquid is leaking out of
the machine, switch the device off
immediately.
Maintenance and cleaning should be per-
formed so that persons doing maintenance
jobs or other persons are not in danger due
to dangerous dust that may appear, adheres
or is being settled on the device.
It is required to have the device checked for
safety technical function at least once a year
by a well-trained professional.
While operating the device in closed rooms,
sufficient ventilation must be provided. Any
additional national or local regulations must
be respected.
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
The vacuum cleaner must not be connected to
the source of electric current with the switch in
the position "OFF".
The parts of the accessories are
delivered in the vessel of the vacuum
cleaner and they must be removed before
bringing it in operation.
If using en extension cable, the following
minimum cross-sections of the conductors must
be observed:
CAUTION!
1. Open the closing clamps (4) and take off the
upper section of the vacuum cleaner. Take
out the parts of accessories from the waste
vessel (fig. 1;2).
2. Insert the waste bag (11) following the
instruction manual into the basket for
impurities (5) (Fig. 4). Slide on tightly the
filtration bag flange onto the hose's
connecting opening (7) (Fig. 6).
Option:
2b. Insert the waste bag (12) following the
instruction manual into the basket for
impurities (5) (Fig. 5). Slide on tightly the
filtration bag flange onto the hose's
connecting opening (7) (Fig. 6)
3. Mount the upper section of the vacuum
cleaner back and close the closing clamps.
Pay attention to a proper position of the
clamps!
4. Connect the suction hose (fig. 7).
5. The operating voltage shown in the machine
plate must comply with the voltage in the
mains.
6. It is recommended to connect the vacuum
cleaner via an overcurrent protection.
7. Connect the plug of the lead-in cable to the
source of electric current.
Before bringing in operation
13
Length of the cable Cross section
Up 20 m 1,5 mm
From 20 to 50 m 2,5 mm
2
2
Switching on the vacuum cleaner (fig. 4)
Bring the switch (3) to the position MAN. The
suction motor starts running
Attendance and operation
