03
7
9
8
10
11
12
13
TIP!
Push the “back snap faste-
ner” into the socket in the
back under the neck guard
on the inside of the helmet
by pushing down hard.
Now pull the chin strap
through the guides on both
sides of the back part of the
neck guard (to do so, it is
best to push the neck guard
outwards again).
There are two more fasteners at
the front of the chin strap (Fig.
6). Snap both of these into the
sockets on both sides (circles).
Lock them into place by pulling
slightly, so that they point to the
inside of the helmet (Fig. 11).
Once you have made final
adjustments to your chin
strap, the excess part of the
strap can be cut off and the
cut edge can then be melted
using a lighter.
Make sure the tension
of the chin strap is the
same on both sides!
