73
CAUTION!
Personal injury or mat eria l damage due to
sudden folding down of the carrier.
Body parts or obj ect s under or in front of the
carrier when it is folded down may be trapped.
• Make sure that t here is nothing under the
carrier.
• Keep all body part s, and particularly your
head, clear, and maintain a suitable safety
distance.
• Hold the carrier by the U-bracket when
folding it down. With you r foot loosen the
locking device (1.) and then tilt the carrier
downward with your ha nd (2.)
Tilting the bicycle carrier, access to the
luggage space
ATTENTION!
Material damage due t o opening tailgate.
The tailgate could impact again st the bicycle
carrier and be damaged.
• Switch off electric tailgates and operate
them manually.
• Fold down the bicycle carrier before
opening the tailgate.
NOTE
The assembly of a third bicycle is done using
the free wheel stoppers on the tyres as with
the attachment of the first and second
bicycles. The third bicycle is additionally
connected to the centre bicycle frame with the
short lock bracket.
DIAMANT SG3:
Assembly of a thi rd bic ycl e
WARNING!
Personal injury or mat eria l damage due to loss
of the bicycle carr ier during the journey.
Carrying bicycles without using the safety
straps can lead to accidents.
A loose connection between the bicycle carrier
and bicycle can lead to detachment of the
connection and loss of the bicycle.
• Carefully observe all w arnings on page 70.
Tilt bicycle carrier
