TEN Manual
• INSTALLATION WITH THE “LATCH75”
Features:
• Small measurements and nice
design
• Easy to install
• Screw provided
• No predetermined breaking
point
• Tolerance +/- 1.0 mm
• 12.5 mm diameter
• Combine the TEN and the
locking device only on request.
• 3070 MINI LOCKING DEVICE FOR ELECTRONIC LOCKS
This latch is used at sliding doors as well as at the back
wall of a drawers. The latch has a predetermined
breaking point of 35 kg.
The flexible pin allows a tolerance +/- 2 mm.
The "latch75" locking part is
available under the following
item numbers:
• “latch75“ with rated break-
ing point
• “latch75s“ without rated
breaking point
