Technical specifications:
Connection Engine power Splitting lift
Split wood length
Hydraulic pressure
Splitting force Weight
Safety instructions
The appliance meets EN 61000-3-11 requirements and is subject to special connection conditions. That means that use on
optionally selected connection points is inadmissible. The appliance can lead to occasional voltage fluctuations under unfavourable
power conditions. The appliance is only designated to be used for connection points not exceeding the maximum allowed impedance of
Zmax = 0,233 Ω. As a user, you must make sure your connection point on which you want to use the appliance meets the above-
mentioned requirements - after agreement with your electricity supplier if necessary.
General
For safety reasons, safety instructions mentioned in these Operating Instructions and instructions on the appliance regarding the
operation, maintenance and repairs must be respected and followed.
Operating personnel
Risks may be associated with using the log splitter. Therefore, only trained and experienced persons may handle and work
with the appliance. The operator must wear tight, close-fitting clothing and protective shoes.
Persons below 18 years of age must not work with the wood splitter. However, persons over 16 years of age may work with
the wood splitter to achieve the learning goal and if supervision by a professional is provided.
Place of work
To ensure safe wood splitting, it is necessary that the place of work is level and enables stability keeping and sufficient free movement.
All obstacles must be removed from access paths for carrying the splitter. Appropriate lighting of the place of work must be provided.
Work preparation
Electric current supply must be interrupted by unplugging the appliance and pressing the red button for repairs or servicing the log
splitter. Interrupting the electric current supply just by putting the switch to OFF is not enough. log splitters are always
supplied with hardened splitting knives. However, if slight deformation of the knife edge after splitting wood containing invisible foreign
items, e.g. out of concrete, steel, etc., it must be removed by a file or grinding off. Keeping the splitting knife sharp at all times increases
the operating power.
TIP: Lubricate the splitting knife with grease from time to time (for problem wood).
Before the splitter is put into operation for the first time, it is necessary to check the safety devices (two-lever operation, in
particular).
CAUTION! Before the appliance is to be put into operation, make sure the splitter table is fitted safely on the splitter.
Technical specifications:
Technical specifications: LS8000B/230V LS8000B/400V
Connection: 230 V~50 Hz 400 V~50 Hz
Motor power 3,5 kW P1 3.0 kW P1
Max. hydraulic pressure: 280 bar 280 bar
Max. splitting force: 8 tons 8 tons
Max. splitting lift: 550 mm 550 mm
Weight: ca. 113 kg app. 110 kg
2
LS6000B/230V LS6000B/400V
230 V~50 Hz 400 V~50 Hz
3,5 kW P1 3.0 kW P1
210 bar 210 bar
6 tons 6 tons
550 mm 550mm
ca. 106 kg app. 103kg
It must be installed and fixed using screws of M10X150 on a hard base to be appropriately stable
Before the splitter is put into operation for the first time, it is necessary to check the safety devices (two-lever operation, in
particular).
CAUTION! Before the appliance is to be put into operation, make sure the splitter table is fitted safely on the splitter.
S6 40%, continuous operation periodic duty: time of one load cycle is 10 minutes, operation time at constant
load is 4 minutes, operation time at no-load is 6 minutes.
No heavy load
S6 40%
S6 40% S6 40%
S6 40%
