Installation of operating arms
Operating arms
1. Fit the operating arm and insert the tube in the cross coupling recession.
TIP: Lubricate the sheet couplings with grease from above and from below!
2. Put the holding pin through before the cross coupling.
3. Set the clamping plates to the corresponding wood diameter.
4. Secure the holding pin with a cotter at the
bottom (included in the supply).
Mazání
tukem
4
1
2
5
