Engine : 4 stroke DTS-i, Single
cylinder 4 valve (2
Intake & 2 Exhaust)
Natural air cooled.
Bore x Stroke : 54.0 mm x 58.8 mm
Eng. Displacement : 134.66 cc
Compression Ratio : 9.8:1
Idling Speed : 1400 RPM
Max. Net Power : 13.5 PS @ 9000 RPM
Max. Net Torque : 11.4 Nm @ 7500 RPM
Ignition System : DC, Digital CDI with
TRICS
Spark Plug (2 Nos) : CHAMPION, PRZ9HC
& BOSCH UR4AC
Spark Plug Gap : 0.6~0.7 mm
Lubrication : Wet sump, Forced.
Transmission : 5 speed constant
mesh.
Front Brake : Hydraulic operated 240
mm disc brake
Rear Brake : Mech. expanding shoe
130 mm dia. Drum
Fuel Tank Capacity :
Full : 8.0 liters
Reserve : 2.5 liters
Usable : 1.6 liters
Dimensions :
Length : 1995 mm
Width : 765 mm
Height : 1045 mm
Wheel base : 1325 mm
Ground clearance : 170 mm
Technical Specifications
