7. Reserve Indicator : It shows reserve position when
petrol left in the petrol tank is 2.5 ltr. Approx.
8. Neutral Indicator : When transmission is in Neutral
and Ignition switch ‘ON’, the Neutral indicator is lit.
9. Trip Meter Reset Button : Trip meter can be reset
to zero by pressing the button.
10. Trip Meter : The Trip meter shows the distance
travelled since it was last reset to zero.
11. Battery Indicator : Shows battery charge condition.
This icon means battery is in charged condition.
Pop-up of this iocon means battery is in low charged
condition.
LOWLOW
Speedometer Details
8
1. Speedometer : The vehicle speed is displayed in
digit.
2. Fuel Level Indicator : Shows available fuel in tank.
3. Tachometer : It shows the engine speed in RPM.
4. Odometer : It shows cumulative reading of total
distance covered by vehicle in Km.
5. Turn Signal Indicator (LH & RH) : When Turn signal
switch’s knob is turned to Left or Right, Turn pilot
indicator - LH or RH will flash.
6. Hi Beam Indicator : When Headlight is ‘ON’ & Hi
beam is selected with engine running, Hi beam
indicator will be lit.
5
4
10
11
3
6
8
7
9
2
1
