1011-Parts Legend
1. ½" x 2½" NPT Nipple
2. PTFE (plumber's) Tape
3. Chrome 90˚ w/ Cone Washer
4. Tapered Plastic Washer
5. Chrome Finned Nut
6. Escutcheon Base
7. Escutcheon Cover
8. Thin Escutcheon (Optional)
9. Supply Line
10. 2.5 GPM Flow Restrictor
11. Screened Rubber Washer
12. 90˚ Inlet
13. Mount ............................ (2)
14. Mounting Screw ............ (2)
15. Metal Washer ................ (2)
16. Nylon Anchor ................. (2)
17. #4 x 1/2" Screw .............. (8)
18. Cover Plate ..................... (2)
19. Hand Shower
20. Hand Shower Holder
21. Hand Shower Hose
22. 4mm Rubber Washer .... (2)
23. Showerhead
24. 6mm Rubber Washer
25. Shelf
