Pulse Mojave 1016 - Parts Identification; Parts Legend and Diagrams

4
Parts Legend
1. ShowerSpa
2. Shower Arm
3. Shower Head
4. Large Rubber Washer ... (2)
5. Brass Nut ........................ (2)
6. Shower Arm Outlet
7. Shower Arm Supply Line
8. Hand Shower
9. Hand Shower Hose
10. Hand Shower Holder
11. Mounting Screw A
12. Nylon Anchor A
13. Hand Shower Outlet
14. Mount Bracket
15. Mounting Screw B ......... (2)
16. Nylon Anchor B ............. (2)
17. Rubber Washer .............. (4)
18. Glass Shelf
19. Shelf Mount ................... (2)
20. Shelf Set Screw .............. (2)
21. Set Screw
