Edition from 03.06.2015
11
PLC330. Multichannel stepper motor driver
www.purelogic.ru8 (800) 555 63 74
Fig. 5. General scheme of CNC control
Brushless spindle
Power unit
Stepper motor/
Servo motor
Frequency
converter
Dumper
Some driver models
have input dumper
CNC controller
Stepper motor
driver
Up to 4 drivers connection
PC with installed CNC
program MACH3
Power unit
Limit sensor
Up to 5 sensors
connection
27V 27V 12V
Ethernet / USB
LPT-cable
Connection via
Relay up to
3 devices
Control
LPT-cable
~220
,
Vacuum
hold down
Cleaner
Cooling fan
Spindle
KRESS
Coolant
pump
~220
,
~220
,
06. Stepper motor connection
