Parameter Description Values
0 Software revision 20 = version 2.0, 12 = version 2.1 etc
1 12 / 24 Hr mode 0 – 12 Hr (default)
1 – 24 Hr
2 Date format 0 = MM.DD.YY (default)
1 = DD.MM.YY
2 = YY.MM.DD
3 Leading zero blanking
eg. 01:54:32
0 – leading zero blanked (default)
1 – leading zero displayed
4 Night Mode start hour 0 - 23
5 Night Mode end hour 0 - 23
6 Night Mode 0 – Tubes off
1 – Dimmed display (default)
7 Master Blank start hour
1
0 - 23
8 Master Blank end hour
1
0 - 23
9 Master Blank days
1
0 – Off (default)
1 – Weekdays
2 - Weekends
3 – All days
10 Colon neons mode 0 – Both off
1 – AM/PM Indication, left / right
2 – AM/PM Indication, left / right flashing
3 – AM/PM Indication, top / bottom
4 – AM/PM Indication, top / bottom flashing
5 – All slow flashing
6 – Slow flashing left / right
7 – All flashing
8 – Both illuminated
9 – Railroad fast
10 – Railroad slow
11 Colon neons during
night dimmed mode
2
As per parameter 10
12 Radio time signal
source
3
0 to 3 reserved
4 – GPS
5 - XTERNA
13 GPS Baud rate 0 – 4.8 Kbps
1 – 9.6 Kbps (default)
14 Radio time offset hours 0-13 (default 0)
4
15 Radio time offset mins 0-45 (default 0)
4
16 Radio time offset
polarity
0 - Minus time (default)
1 – Plus time
17 Reserved
18 Snooze period 0 – 6 minutes (default)
1 – 9 minutes
2 – 12 minutes
3 – 15 minutes
19 Reserved
20 Time Calibration Factor 0 - 99 (each unit adjusts by 0.2s per day)
21 Time Calibration Polarity
0 - Make clock slower
1 - Make clock faster
22 Slots Mode
5
0 – Slots disabled
