www.PyleUSA.com
4
7. : In USB/Micro SD Memory Card reading status, short press it to go to the
previous track. In FM receiving status, short press to select the next channel after
a full station search has been executed.
8. Mode/SHIFT: Short press to toggle between USB/Micro SD Memory Card and
FM receiving modes. long press it to toggle between recording folder and MP3
folder.
9. Recording/DEL: Short press to enable recording (USB/Micro SD Memory Card
storage device needs be connected rst). During recording, reverberation
should be tuned to minimum. Press and hold to delete a recorded le.
Recording in AUX or FM mode is available.
10. EAR MIC: Headphone/MIC Port
11. EQ: Environment Switching: In USB/Micro SD Memory Card reading status,
short press to select an environment mode (from Square, Meeting, Home, Hall
and Personal).
12. BASS: The bass control knob
13. LINE IN: External sound source input port (plug-and-play).
14. Microphone Volume: Microphone volume regulating knob.
15. Reverberation: Microphone reverberation regulating knob.
16. Microphone Input: Microphone input jack
17. DC 12V Recharging: DC 12V recharging port.
18. : Control the ash light switch.
19. Recharging Indicator Light: When the charger is connected, red light turns
on. When the device is fully charged, blue light turns on.
20. Power Switch: “ ” - ON; “ ” - OFF.
21. TREBLE: The control knob of treble
22. IR: Infrared remote receiver module
