Pyle view PLCM7200 User Manual

PLCM7200
Wire diagramFunction keys panel
1
2
3
5
6
4
1. Remote window
2. Analog variable increase
3. Menu
4. Analog variable decrease
5. Exchange between V1/V2
6. Power on/off
Press MENU to display the adjustments in this order.
Brightness-->Color-->Contrast-->Volume-->...
Power ON/OFF
Analog variable increase
Menu button
V1/V2 conversion
Analog variable decrease
Switch for mode
Methods of remote using
(Green)reverse car
PLAYER
CAMERA
(Red) battery+12v
(Black)grounding
(Yellow) video 1 input
(Yellow) video 2 input
PLCM72 00

Pyle view PLCM7200 Specifications

General

Brand	Pyle view
Model	PLCM7200
Category	Automobile Accessories
Language	English
