The PDWM2130 was manufactured to be easy to use and still give you professional performance quality in
and FM wireless microphone.
Installation is so simple.
• Unscrew the bottom of the microphone to install two AA Batteries. Screw
the Battery cap back on.
• Plug your receiving unit into your mixer or amplifier with a 1/4" mono
microphone cord.
• Plug the receiving unit into your electrical wall outlet.
• Turn the receiver on by using the on/off switch located at the front of the
unit.
• There is a switch located on each of the two microphones that turns each
microphone on/off & mutes them individually.
• Your wireless microphone system is up and running.
WIRELESS MICROPHONE
Carrier Frequency: 109.00~113.00MHz
Tx output level: 10MW
S/N ratio: 75dB
Maximum deviation: 30KHz
Modulation mode: FM
Battery type: 3V
RECEIVER
Carrier Frequency: 109.00~113.00MHz.
RF Sensitivity: 20dB/
S/N ratio: 50dB
Frequency response : 50~15KHz
Audio output level: 10mV
Power: DC: 9 V, A C: 110V o r 2 2 0 V
