Pyle PPHP1049KT User Manual

www.PyleUSA.com
PPHP1049KT
1. LCD screen
2. Mp3 control
MODE: USB/SD/BT/FM convertor
: Play / Pause
SCAN: Long press to auto search
under FM radio
FOL: Long press 5 seconds to enter
the folder option function mode
(press the previous/next songs
button to choose the folder)
: Repeat one / Repeat all / Random
: PRE/NEXT under FM mode Long
hold to search lower/ higher station
manually
: Short press to tune to saved station
: Previous Song
Long press for fast rewind
: Next Song
Long press for fast forward
3. USB input
4. SD card input
5. Remote control
6. MIC level control
7. MP3 level control
8. Basscontrol
9. Treble control
10. XLR microphone line input
11. Line input
12. AUX input
13. Master volume
14. Speaker out 8Ohm
15. Main power switch
16. Fused IEC mains inlet
IR
MP 3 CONTR OL DIGITAL DI SPLAY
US B
SD c ard
MI C
LI NE IN
PO WER SWITC H
AC :100-24 0V 5 0/60Hz
8Ω
SP EA KE R OUT
MI C VO L MP 3 VO L
TR EB LE
AU X
MA STER VOL
BA SS
-1 2 +1 2 -1 2 +1 2
3
4
1
2
9
13
14
6
10
16
15
11
12
8
7
5
MI N MA X
MI N MA X
MI N MA X
3

Pyle PPHP1049KT Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Tweeter	Yes
Speaker type	2-way
Number of drivers	1
Speaker placement	Floor
Audio output channels	2.0 channels
Tweeter diameter (imperial)	1 \
Subwoofer driver diameter (imperial)	10 \
Amplifier class	D
Display	LCD
Impedance	8 Ω
Sensitivity	92 dB
Frequency range	65 - 18000 Hz
RMS rated power	- W
Peak Music Power Output (PMPO)	1000 W
Total Harmonic Distortion (THD)	1 %
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD
Connectivity technology	Wired & Wireless
AC input voltage	100 - 240 V
Power source type	AC

Weight and Dimensions

Depth	762 mm
Width	622 mm
Height	1193.8 mm
Weight	8200.9 g
