Pyle PPHP155ST User Manual

PPHP155ST
1. LCD Screen
2. MP3 Control
MODE: USB/SD/BT/FM Convertor
: Play/Pause
: Repeat one / Repeat all / Random
FOL (FOLDER): Press and hold for 5 seconds to enter the folder option
function model (press the previous/next songs button to choose the folder)
: Previous song, Press and hold for 2 seconds to lower the volume,
Press and hold the volume will go down to zero
: Next song, Press and hold for 2 seconds to increase the volume,
Press and hold the volume will go up to 25
3. SD card input
4. USB Input
5. Clip LED indicator
6. Power LED indicator
7. Mic 1 input level control
8. Mic 2 input level control
9. Line input level control
10. Volume control
11. Treble control
12. Bass control
13. XLR microphone input
14. 6.35mm microphone input
15. RCA phono (R+L) line input
16. 6.35mm line output
17. XLR line input
18. XLR line output
19. Speaker out 8 Ohm
20. Fused IEC mains inlet
21.120 - 240V Switch
22. Main power switch
www.PyleUSA.com
2

Pyle PPHP155ST Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Tweeter	Yes
Speaker type	2-way
Number of drivers	1
Speaker placement	Floor
Audio output channels	1.0 channels
Woofer diameter (imperial)	15 \
Tweeter diameter (imperial)	1 \
Amplifier class	A/B
Impedance	8 Ω
Sensitivity	98 dB
Frequency range	40 - 18000 Hz
RMS rated power	- W
Peak Music Power Output (PMPO)	1500 W
Total Harmonic Distortion (THD)	1 %
Bluetooth range	30 m
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
AC input voltage	100 - 230 V
Power source type	AC

Weight and Dimensions

Depth	350.5 mm
Width	431.8 mm
Height	685.8 mm
Weight	- g
