4
11. SD input
12. USB input
13. TIME: Effect Delay Time
14. EQ: 5 band graphic equalizer
15. EFF VOL: Master Effect Volume Level
16. LINE IN: LINE 1 input
17. MASTER: Control General Volume Level
18. MIC IN: MIC 1 input
19. Eect volume Level for MIC IN 1/LINE IN 1
20. VOL: MIC IN 1/LINE IN 1 Volume Level
21. MIC IN: MIC 2 input
22. Eect volume Level for MIC IN 2/LINE IN 2
23. VOL: MIC IN 2/LINE IN 2 Volume Level
24. LINE IN: LINE 2 input
25. MP3 VOL: Control Volume of MP3
26. LINE IN:XLR (balanced signal),and line input
27. VOL: Control Volume of LINE IN
28. LINE IN: LINE RCA input (Unbalanced signal)
29. LINE OUT: RCA (Unbalanced signal) channel line output, used for
recording or other linking
30. OUTPUT: XLR (balanced signal) channel line output
31. SPEAKER OUT: Speak on output for connecting a passive speaker
32. POWER: Power Supply Switch
33. Power Supply Input Connector: Using with a power cord.
34. FAN
www.PyleUSA.com
