www.PyleUSA.com
4
2. Blue LED Display
3. USB port
4. SD port
5. Channel 1-4 XLR Connector:
Connect Microphone and Line input using the XLR cables.
6. Mic / Line Input Selector Channels: When connecting a microphone set the
selector to MIC. When connecting a Line input set this selector to Line.
7. Treble Knob: Channels 1-4 have individual treble controls per channel.
Use this knob to adjust the treble levels for the selected channel.
8. Bass Knob: Channels 1-4 have individual bass controls per channel.
Use this knob to adjust the bass levels for the selected channel.
9. Eects Knob: Channels 1-4 have individual eects controls per channel.
Use this knob to adjust the reverb eect levels for the selected channel.
10. Volume Knob: Channels 1-4 have individual volume controls per channel.
Use this knob to adjust the volume levels for the selected channel.
11. 1/4” Line Input: Connect your sound source to this 1/4” input. The line volume
will be controlled by channel 5/6 volume control and master volume Knob.
Only passive signals should be the connected input.
12. RCA Line Input: Connect your sound source to this RCA input (6/7 Channel).
Only passive signals should be the connected input.
13. RCA Line Output: Use this connector to connect other amplier.
DO NOT connect directly to a passive speaker.
14. Line/MP3 Selector: When you use USB SD Bluetooth signal push down, When
you use Mic/Line input signal push the selector up.
15. Signal input Volume Knob:
Adjust the volume for MP3 or MIC/Line signal input.
16. Master Volume Knob: Adjust all the output signal for the powered mixer.
17. Indicator: Displays the signal volume for output.
18. Phantom Power: Press this button to activate the 15V phantom power
necessary for a condenser (capacitance) Microphone which might require 15V
power supply from the mixer Channel 1-4 input.
19. 5 Band Graphic Equalizer: Adjusts the frequency of output signal.
20. Depth Knob:
Adjust the depth eects level of 1-4 Channel for Microphone input.
21. ECHO Volume Knob: Adjusts the ECHO Level for MIC input.
