www.PyleUSA.com
2
PPHP849KT
1. LCD screen
2. Mp3 control
MODE: USB/SD/BT/FM convertor
: Play / Pause
SCAN: Press and hold to auto
search under FM radio
FOL: Press and hold for 5 seconds
to enter the folder option function
mode (press the previous/next
songs button to choose the folder)
: Repeat one / Repeat all / Random
: PRE/NEXT under FM mode
Press and hold to search lower/
higher station manually
: Short press to tune to saved station
: Previous Song
Press and hold for fast rewind
: Next Song
Press and hold for fast forward
3. USB input
4. SD card input
5. Remote control
6. MIC level control
7. MP3 level control
8. Bass control
9. Treble control
10. XLR microphone line input
11. Line input
12. AUX input
13. Master volume
14. Speaker out 8Ohm
15. Main power switch
16. Fused IEC mains inlet
MIN MAX
IR
MP3 CONTROL DIGITAL DISPLAY
USB
SD card
MIC
LINE IN
POWER SWITCH
AC:120-240V 50/60Hz
8Ω
SPEAKER OUT
MIC VOL MP3 VOL TREBLE
AUX
MASTER VOL
BASS
-12 +12 -12 +12
3
4
1
2
9
13
14
6
10
16
15
11
12
8
7
5
MIN MAX
MIN MAX
