4
CONTROLS
1. USB Display
2. USB and SD socket
3. Previous song/channel, long press this button to reduce the volume
4. Play/Pause
5. Next song/channel, long press this button to increase the volume
6. MODE: USB/SD/FM/BLUETOOTH/AUX function of conversion
7. Power Indicator
GREEN LED: ON
CHARGING: Red LED light on (Low battery, red LED will ash)
FULL: Blue LED light on
8. MICROPHONE INPUT 1:
Balanced microphone Connector
9. MICROPHONE INPUT 2:
Balanced microphone connector
10. AUX INPUT
Allows cassette recorder or CD player to the Main output.
11. DC IN 15V
12. MICROPHONE VOLUME LEVEL
Allows you to increase or decrease the volume level.
13. ECHO
Allows you to increase or decrese the ECHO level
14. TREBLE
15. BASS
16. VOLUME
Allows you to increase or decrease the volume level.
17. ON/OFF SWITCH
Powers the device ON/OFF.
