2. Some displays have curved backs with
recessed mounting lands(Fig.a). It will
require the use of spacer. For this display,
install a spacer(K) between display and
thebracket.AsshowninFig1b.
Fig a
-4-
-5-
Following examples shows how to use bolts, spacers and square washers.
1.Some displays have vertical backs. No spacer is required. Install the bracket directly
to the back of display by using bolts and square washers provided. As shown in Fig.1a.
Fig 1a
M5 Fig bitM4 Fig bit
M6 Fig bit
A,B
3
G
2
C
G
D
G
3
Fig 1b
M6 Fig bitM5 Fig bit
E
3
G
K
K
F
G
3
