GENERAL DESCRIPTIONS
RE M AR K S
1
SYSTEM FUNCTION FIGURE
2
1.It is consist of one set of of wireless and two wired microphone
input circuits, both of them has separated volume control.
2.The standard accessories are VHF high band wireless transmitter
and receiver.
3.It is equipped with built-in 4.5AH/12V rechargeable battery
which can be charge 6 hours continuously, also DC power can be
used directly.
4.One guitar input function and one audio input unit both are
supplied.
5.Treble and bass control are supplied.
6.Echo control is supplied.
7.With voltage selector switch for selecting a suitable one
according to different countries.
8.8＂full range driver
1.Correct power must be used, don't use any other power except
the specified one.
2.Don't drag the power cable when pull out the plugs, just hold
the plug to pull it out from socket.
3.Don't open chassis: it is very dangerous either open the chassis
or put your hand inside the chassis, don't do it. If the device is
not under normal working, pull out the plug at once and contact
your retailer or nearest distributor.
4.Don't take volatile solvent such as toluene, alcohol, gasoline to
clean the surface.
5.Please don't put it in a unventilated environment or at direct
sunlight in summer.
6.Avoid moisture or rain
1.Wireless Mic/MIC1 Volume Control
2.MIC2 Volume Control
3.Guitar Volume Control
4.Audio Volume Control
5.Ipod/MP3 Volume Control
6.Echo Control
7.Treble Control
8.Bass Control
9. Metal Corner
10. bluetooth on/off switch
11. bluetooth indicator light
12. Audio Output Jack
13. Ipod/MP3 Input Jack
14.Audio Input Jack
15.Guitar Input Jack
16. Vent Hole
17. Fixed Stand For The Unit
18. Vent Hole
19. Woofer Speaker
20.MIC2 Input Jack
21.MIC1 Input Jack
22. Power Switch
23. Power Indicator
24. Low Voltage Indicator
25. Charge Indicator
26. RF Indicator For Wireless Mic
1 2 3 5 6 7
8
9
10
11
12
26
25
24
23
22
21
19
4
20
16
18
17
13
14
15
PW MA2 30 BT
