Step 8
For the other end of the gate with the “recessed” hinges,
you will use Hinge Bracket A both at the top and bottom.
Place the Top Hinge Covers on both the top and bottom
hinges. Slide Wall Bracket A over the top hinge and insert
Connecting Spindle. Slide the second Wall Bracket A
onto the Connecting Spindle with the cone shaped end
down.
Step 9
Attach the Wall Plates to the Wall Brackets by aligning
the key slots and slide in until the Wall Place locks into
place.
IMPORTANT:
REGARDING THE INCLUDED MOUNTING SCREWS!
Before marking where to attach the gate, make sure you
have chosen a solid surface for mounting the gate to. The
included screws are intended for the following locations.
Directly into wood
The Short Screws 3/4” (19 mm) are
used when mounting directly into
wood, for example in a door frame
or other framed opening. If installing
into hardwood, first drill a pilot hole.
Into a stud behind drywall
Use a studfinder to locate where there
is a stud behind the drywall. Then use
the Long Screws 1.5″ (38 mm) to mount
the gate into the stud.
Any other surface
If mounting into drywall, brick or other surface, use
only the appropriate hardware for that surface. Consult
with a certified child proofer, a handyman or your local
hardware store if you are unsure.
Wall Bracket A
Recessed
Hinge
Cover
Recessed hinge
Wall Bracket A
