8
EN
2. TECHNICAL SPECIFICATIONS
Power supply 220 - 240 V~, 50 Hz
Rated current 0.6 A
Energy consumption 197 kWh/year
Protection class I
Climate class N/ST
Total volume 64 L
Freezer compartment volume 64 L
Freezing capacity 3kg/24h
Refrigerant and inject amount R600a/31g
Net weight 25 kg
3. PRODUCT DESCRIPTION
1. Thermostat knob
2. Flip cover
3. Freezer drawers
4. Adjustable feet
4. INSTALLATION
4.1. INSTALLATION LOCATION
1. Ventilation condition
The position you select for the refrigerator installation should be well-ventilated and has
less hot air.
Do not locate the refrigerator near a heat source such as cooker, and avoid
it from direct sunlight, thus guaranteeing the refrigeration eect while saving
energy consumption.
Do not locate the refrigerator in a damp place, so as to prevent the refrigerator
from rusting and leaking electricity.
The result of the total space of the room in which the refrigerator is installed being
divided by the refrigerant charge amount of the refrigerator shall not be less than 1m³
(space) / 8g (refrigerant).
Note: The amount of refrigerant charged for the refrigerator can be found on the
nameplate.
2. Heat dissipation space
When working, the refrigerator gives o heat to surroundings. Therefore, at least
30 mm of free space should be spared at the top side, more than 100 mm on both
sides, and above 50 mm at the back side of the refrigerator.
Dimensions in mm:
W D H A B C(°) E F
470 509 845 900 975 125±5 50 100
