Product Specications
※
Models with an asterisk mark (*) have certication.
※
CE compliant : DC24V
,
DC12V/24V(ST80EL
,
ST80EL)
※
UL listed : DC24V
Model number
Layer
count
Voltage Certicate Weight Color
* ST80ML
* ST80ML-BZ
ST80ML-WS
ST80ML-WM
ST80ML-WA
ST80MLF
ST80MLF-BZ
ST80MLF-WS
ST80MLF-WM
ST80MLF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.40kg
0.40kg
0.64kg
0.64kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.54kg
0.54kg
0.78kg
0.78kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.68kg
0.68kg
0.92kg
0.92kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.83kg
0.83kg
1.06kg
1.06kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.97kg
0.97kg
1.20kg
1.20kg
R-Red
A-Amber
G-Green
B-Blue
W-White
Model number
Layer
count
Voltage Certicate Weight Color
* ST80MEL
* ST80MEL-BZ
ST80MEL-WS
ST80MEL-WM
ST80MEL-WA
ST80MELF
ST80MELF-BZ
ST80MELF-WS
ST80MELF-WM
ST80MELF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.36kg
0.36kg
0.59kg
0.59kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.45kg
0.45kg
0.68kg
0.68kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.55kg
0.55kg
0.76kg
0.76kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.64kg
0.64kg
0.87kg
0.87kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.73kg
0.73kg
0.96kg
0.96kg
R-Red
A-Amber
G-Green
B-Blue
W-White
Model number
Layer
count
Voltage Certicate Weight Color
* ST80L
* ST80L-BZ
ST80L-WS
ST80L-WM
ST80L-WA
ST80LF
ST80LF-BZ
ST80LF-WS
ST80LF-WM
ST80LF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.62kg
0.62kg
0.86kg
0.86kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.77kg
0.77kg
1.00kg
1.00kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.91kg
0.91kg
1.14kg
1.14kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
1.05kg
1.05kg
1.29kg
1.29kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
1.19kg
1.19kg
1.14kg
1.14kg
R-Red
A-Amber
G-Green
B-Blue
W-White
Model number
Layer
count
Voltage Certicate Weight Color
* ST80EL
* ST80EL-BZ
ST80EL-WS
ST80EL-WM
ST80EL-WA
ST80ELF
ST80ELF-BZ
ST80ELF-WS
ST80ELF-WM
ST80ELF-WA
1
AC/DC12V
AC/DC24V
AC110V
AC220V
0.58kg
0.58kg
0.81kg
0.81kg
R-Red
2
AC/DC12V
AC/DC24V
AC110V
AC220V
0.67kg
0.67kg
0.91kg
0.91kg
R-Red
G-Green
3
AC/DC12V
AC/DC24V
AC110V
AC220V
0.77kg
0.77kg
1.00kg
1.00kg
R-Red
A-Amber
G-Green
4
AC/DC12V
AC/DC24V
AC110V
AC220V
0.86kg
0.86kg
1.09kg
1.09kg
R-Red
A-Amber
G-Green
B-Blue
5
AC/DC12V
AC/DC24V
AC110V
AC220V
0.95kg
0.95kg
1.19kg
1.19kg
R-Red
A-Amber
G-Green
B-Blue
W-White
•
ST80ML
•
ST80MEL
•
ST80L
•
ST80EL
• Light source / buzzer current (based on 1 layer)
Model number Current AC/DC12V AC/DC24V AC110V AC220V
ST45ML
ST45L
Light source current(1 layer) 40mA 55mA 45mA 30mA
buzzer current 40mA 75mA 50mA 35mA
Signal sound current 200mA(DC12V) 135mA(DC24V) 50mA 35mA
ST56MEL
ST56EL
Light source current(1 layer) 60mA 60mA 50mA 40mA
buzzer current 40mA 75mA 50mA 40mA
Signal sound current 200mA(DC12V) 135mA(DC24V) 50mA 35mA
ST56ML
ST56L
Light source current(1 layer) 120mA 95mA 70mA 55mA
buzzer current 40mA 75mA 50mA 40mA
Signal sound current 200mA(DC12V) 135mA(DC24V) 50mA 35mA
ST80MEL
ST80EL
Light source current(1 layer) 80mA 60mA 50mA 40mA
buzzer current 40mA 75mA 50mA 40mA
Signal sound current 200mA(DC12V) 135mA(DC24V) 50mA 35mA
ST80ML
ST80L
Light source current(1 layer) 160mA 95mA 70mA 55mA
buzzer current 40mA 75mA 50mA 40mA
Signal sound current 200mA(DC12V) 135mA(DC24V) 50mA 35mA
