Qlima BWK 1607 User Manual

Temperature setting
• The temperature setting range is 5-22 ºC (BWK 1607, 5-18°C).
• Directly touch the mark
or to set the Wine Cooler temperature as you
want.
• The first touch on mark
or will recall the previous set temperature dis-
played in the digital window. If the appliance runs after a power failure (or
unplugging), the previous set temperature does not exist and is replaced by
the default temperature at 12ºC.
• Touch the mark
to increase the set temperature by 1ºC. On the contrary,
touch the mark
to decrease the set temperature by 1ºC.
• The digital will change to display the real temperature of the inside cabinet
after 10 seconds without being touched.
Operation
Control Panel
BWK 1622
Single Zone
Overtime Open the Door Alarm
• When you forget to close the door or the door is not closed completely, the
buzzer alarms after 5 minutes. Please close the door completely and avoid
the cold energy was lost.
Temperature Alarm
• If inner temperature is higher than 23°C, The “HI” is shown in display panel,
and the buzzer alarm after one hour continuously. It informs that the inner
temperature is too high, please check the reason.
• If inner temperature is lower than 0°C, The “LO” is shown in display panel,
and the buzzer alarm and the malfunction indicator light lights at the same
time.
• When removing any of these shelves out of the rail compartment, tilt the
shelf as per the pic. 8 and simply pull out.
Operation
Control Panel
BWK 1651
FWK 16110
FWK 16154
Dual Zone
Power On/Off
• When the appliance is plugged in to a power outlet, it powers on automati-
cally.
• Touch the power mark
to turn off (or turn on) the appliance.
Temperature setting
• The temperature setting ranges are 5-12 ºC for the upper zone and 12-22 ºC
for the bottom zone.
• Press
for desired zone once. The display with digital flashing indicates the
zone ready for temperature setting.
Lighting
4
78
Set
Upper
Zone
Set
Lower
Zone
Display
Upper
Zone
Display
Lower
Zone
°C / °F interchange
Power
Power

Qlima BWK 1607 Specifications

General

Inner color	Black
Housing color	Silver
Number of doors	1 door(s)
Reversible doors	Yes
Shelves material	Wood
Number of shelves	7 shelves
Appliance placement	Built-in
Noise level	44 dB
Product type	Compressor wine cooler
Climate class	N
Bottles capacity	7 bottle(s)
Total net capacity	20 L
Refrigerating medium	R600a
Temperature range (zone 1)	5 - 18 °C
Number of temperature zones	1
Current	0.5 A
Connected load	70 W
AC input voltage	220 -240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to G
Annual energy consumption	135 kWh
Lamp type	LED
Door open alarm	No
Package depth	510 mm
Package width	175 mm
Package height	890 mm
Package weight	21000 g

Weight and Dimensions

Depth	471 mm
Width	145 mm
Height	865 mm
Weight	19000 g
