MANUAL
A INSTALLING THE HEATER
1
Carefully remove your heater from the box and check the contents.
In addition to the heater you also need to have:
E a manual fuel pump
E a transportation cap
E these directions for use
Keep the box and the packaging materials (Fig. A) for storage and/or
transportation.
2
Open the lid of the tank compartment C and remove the piece of cardboard.
3
Fill the removable tank as indicated in Section B.
4
The floor should be firm and completely level. Reposition the heater, when it
is not level. Do not try to correct the situation by placing books or other
goods under the heater.
5
Use the horizontal safety bracket K to prevent the curtains from covering the
ventilator (Fig. B.).
6
Insert the plug M into the wall-socket (230 Volts - AC / 50 Hz) and set the
correct time using the adjustment keys (refer to Section C).
7
Your heater is now ready for use.
B FILLING FUEL
Fill the removable tank in a suitable place since there can always be some spillage.
Follow the procedure below:
1
Make sure that the heater is switched off.
2
Open the upper lid and lift the removable tank out of the heater (Fig. C).
Note: Some drops may leak from the tank. Put down the removable tank
(cap pointing upwards, handle on floor and take off the fuel cap.
3
Remove the metal cap. Easy to open by holding the outside (fig. D.).
4
Fill the removable tank using a fuel pump (refer to fuel pump operation
instructions.) Make sure that it is in a higher position than the removable tank
(Fig. E). Insert the ribbed hose into the opening of the removable tank.
5
Check the removable tank fuel gauge while filling the tank (Fig. F). Stop
filling once the gauge indicates that the tank is full. Never overfill the tank,
especially not when the fuel is very cold (fuel expands when it heats up).
6
Let the remaining fuel in the pump flow back into the jerrycan and carefully
4
E E E E E E
67
A
B
C
D
E
