Qls 14N23 - Bill of Materials (BOM) - Part 15

T8-0014SGP-PWY 11-SK2645-0AX TRANSISTOR 2SK2645-01MR (POWER Q815
T8-0014SGP-PWY 13-0HPC92-2CP
TCL13-0HPC92-2CP= PHOTO COUPLER
HPC922-C
IC802
T8-0014SGP-PWY 18-CD0101-JNX RES. C.F. 100 OHM 1/4W +/-5% R813
T8-0014SGP-PWY 18-EF0229-JGX RES. FUS. 2.2 OHM 1W +/-5% R843
T8-0014SGP-PWY 18-FG0229-JHX RES. M.O. 2.2 OHM 2W +/-5% R852
T8-0014SGP-PWY 18-KF0825-JHX RES. GLASS GLAZE 8.2M OHM 1W R829
T8-0014SGP-PWY 18-RG0108-JHX RES. WIRE ROUND 0.1 OHM 2W +/-5% R815
T8-0014SGP-PWY 22-NTC479-XX0 NTC 4.7D2-14 R803
T8-0014SGP-PWY 22-PTC200-XX1 PTC 20 OHM +/-20% MZ73BH RT801
T8-0014SGP-PWY 25-BDA102-M1X CAP. ELEC 1000 UF 25V +/-20% C843
T8-0014SGP-PWY 25-BMJ151-M1X CAP. ELEC 150 UF 400V +/-20% C806
T8-0014SGP-PWY 25-PJG101-M1X CAP.CELE 100UF/160V/+/-20% C835
T8-0014SGP-PWY 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B C841
T8-0014SGP-PWY 26-AIL103-MEX CAP.CER 10NF 500V +/-20% C805
T8-0014SGP-PWY 26-AIL103-MEX CAP.CER 10NF 500V +/-20% C826
T8-0014SGP-PWY 26-AKA221-KRX CAP. CER 220 PF 1KV +/-10% C833
T8-0014SGP-PWY 26-AKM221-KRX CAP. CER 220 PF 1KV +/-10% C809
T8-0014SGP-PWY 26-AMM331-KRX CAP. CER 330 PF 2KV +/-10% C815
T8-0014SGP-PWY 26-APK102-MEX CAP. CER 1000PF 400VAC +/-20%E C829
T8-0014SGP-PWY 26-APK102-MEX CAP. CER 1000PF 400VAC +/-20%E C803
T8-0014SGP-PWY 26-APK102-MEX CAP. CER 1000PF 400VAC +/-20%E C804
T8-0014SGP-PWY 26-AQK472-ZFX
CAP. CER 4700PF 250VAC +80% -20%
F
C808
T8-0014SGP-PWY 26-AQK472-ZFX
CAP. CER 4700PF 250VAC +80% -20%
F
C807
T8-0014SGP-PWY 27-AQT474-MV3 CAP.M.PP0.47UF275VAC+/-20% C801
T8-0014SGP-PWY 27-MHM104-K0X CAP. M.P.E 0.1 UF 400V +/-10% C802
T8-0014SGP-PWY 34-R101K2-1BX COIL CHOKE 100 UH +/-10% L834
T8-0014SGP-PWY 34-R220K2-1BX COIL CHOKE 22 UH +/-10% L843
T8-0014SGP-PWY 35-392170-00X FERR.COIL BF-I35050C-683 L833
T8-0014SGP-PWY 36-LIF004-AX0
TCL36-LIF004-AX0= LINE FILTER
R=N
T801
T8-0014SGP-PWY 36-TRF231-AX0 TRANSFORMER CONV. BCK-2890 T803
T8-0014SGP-PWY 46-10962W-02XG PIN BASE *2 TJC2-2A P803
T8-0014SGP-PWY 50-02000D-1GS1G FUSE 2.0AT 250VAC 5MMX20MM F801
T8-0014SGP-PWY 63-B30100-AB4G
SCREW-ST 3MM 10MM JIS B 1122 53
0 0 R=Y
FOR Q815
T8-0014SGP-PWY 64-B30080-304G TRIANGLE M/C SCREW B 3 X 8 FOR Q843
T8-0014SGP-PWY 66-20516X-0B0 FUSE HOLDER FOR F801
T8-0014SGP-PWY 67-H10918-4M2 HEAT SINK FOR Q843
T8-0014SGP-PWY 67-H41341-2A0 HEAT SINK FOR Q815
T8-0014SGP-PWY 67-M40068-1E4
TV RAW BRACKET TCL CRT -- 00 00
R=N
FOR Q815
T8-0014SGP-PWY 71-DYP000-WX2 LABEL
STICK ON HEAT
SINK
T8-EN23SGP-OT4 07-457FF5-NA9G TUNER F07GP-4ND-E TU101
T8-EN23SGP-OT4 13-TSM123-06M01 MCU TMPA8873CSBNG IC201
T8-EN23SGP-OT4 37-FAAT02-BAA1A 14"FBT BSC25-0214S T402
T8-EN23SGP-OT4 46-33079W-04XG PIN BASE *4 TJC3-4A P905
T8-EN23SGP-OT4 46-33079W-05XG PIN BASE *5 TJC3-5A P002
