Qpod QT - Vehicle Maintenance and Specifications

10
The Bonnet Section
Under T
he
Bonnet
Under The Boot
Note
–
Engine Oil Level ‘Dip Stick’
Engine Oil Filling Point
Radiator Cap
Note
–
The bonnet panel
is secured by four
quick release pins. To remove the
bonnet panel, all of the pins must be
removed by turning them 90
0
anti
-
clockwise with a screw
-
driver. To
replace the bonnet; push down the
pins and turn back 90
0
clockwise with
a screw
-
driver.
The same pins fix down the
boot corners.
1
–
Battery
2
–
Washer Bottle
3
–
Fuse Box
–
(see below)
15 amp
10 amp
10 amp
7.5 amp
7.5 amp
10 amp
1 amp
7.5 amp
-
Main feed to ECU
-
Rear Lights (Fog and Reverse)
-
Headlights
-
Indicators, wiper and was
her
-
Heater Fan
-
Ignition Circuit
-
Dash Warning Lights
-
Side Lights
; Check
the Oil regularly and top up when
required.
; Check water level
regularly and top up with distilled water
wh
en required.
Only check the levels when the
engine is cold and not running.
