8
TSC-70-G3 / TSC-101-G3 Features
Refer to qsc.com for the TSC-G3 Series Specifications Sheet.
Front Panel
1. Ambient light sensor / proximity sensor
2. IR source
3. NFC antenna
4. 7in. 1280 x 800 display (TSC-70-G3) or
10.1in. 1920 x 1200 display (TSC-101-G3)
Rear Panel
1. Docking magnet
2. RJ45, PoE/+ in
3. LAN LEDs
◦ Left: Link/Activity
◦ Right: Speed
4. USB Type C
5. Exhaust vents
Profile
1. Mounting point for wall-mount bracket
2. Regulatory markings
3. Model identification
4. Programmable RGB LEDs
1
2
3
4
1 52
3
4
1
2
4
3
