QUAD C4 - REV 1 - Page 6

Concourse C4, C4-8, C4-16, C4-T
Concourse C6
Concourse C8
Concourse CSUB
219mm/8.62”
219mm/8.62”
349mm/13.74”
331mm/13.03”
371mm/14.6”
238mm/9.37”
293mm/11.54”
333mm/13.11”
212mm/8.35”
252mm/9.92”
212mm/10.04”
295mm/11.61”
6
