Cylinder Mower Elan 32 Concorde 32
Part number F016 300 0.. F016 130 01..
Rated power 350 W 325 W
Blade width 32 cm 32 cm
Height of cut 12 - 42 mm 12 - 42 mm
Grassbox capacity 31 l 23 l
Weight 13.5 kg 11,7 kg
Protection class /
II
/
II
Serial Number See serial No.
10
(rating
plate) on machine
This product is intended for domestic lawn mowing.
This manual gives instructions on the correct assem-
bly and safe use of your machine. It is important
that you read these instructions carefully.
When fully assembled the machine weighs be-
tween approximately 11.7 kg and 13.5 kg. If neces-
sary, obtain assistance to remove from packaging.
Take care when carrying the mower to the lawn, as
the blades are sharp.
Carefully remove the machine from its packaging
and check that you have all the following items:
– Lawnmower with handle assembly
– Handle bottom
– 2 Bolts (fitted to handle bottom)
– 2 Wing nuts (fitted to handle bottom)
– 2 Pivot pins (fitted to handle bottom)
– 2 Pivot covers (fitted to handle bottom)
– 2 Grassbox halves Elan 32
– Grassbox Concorde 32
– Operating instructions
When parts are missing or damaged, please con-
tact the consumer care hotline on (01895) 838782
for assistance. We also have a network of Atco-
Qualcast Approved Service Agents who you can
contact for service and advice both within and
outside the period of guarantee.
1
Handle top
2
Switch lever
3
Safety button
4
Mains plug**
5
Cable restraint**
6
Handle bottom
7
Grassbox
8
Height of cut lever
9
Ventilation slots
10
Serial number
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Electrical Safety
Your machine is double insulated for safety and re-
quires no earth connection. The operating Voltage
is 230 V ac, 50 Hz. Only use an approved extension
cable. Contact your service agent for details.
Extension cords/leads should only be used if they
comply with H05VV-F or H05RN-F types.
It is recommended for increased electrical safety to
use a Residual Current Device (RCD) with a tripping
current of not more than 30 mA. Always check your
RCD every time you use it.
For Product not sold in GB:
WARNING: For safety, it is essential that the mains
plug
4
attached to the machine is fitted to the
power supply cable
11
as in Figure
B
.
The couplings of connection leads must be pro-
tected against splashes and the coupling sockets
on the leads must be made of rubber or coated
with rubber.
Fixing means for the connection leads must be
used.
The connection lead must be inspected for signs of
damage at regular intervals and may only be used
if in perfect condition.
If the supply cord is damaged it must be replaced
by a Atco-Qualcast Approved Service Agent.
Products sold in GB only:
Your mower is fitted with
an approved 13 A (BS1363/A) electric plug and is
protected by a 3 A fuse (ASTA Approved to
BS 1362).
If the fitted plug is not suitable for your socket out-
lets, it should be cut off and an appropriate plug fit-
ted in its place.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be inserted
into a 13 A socket elsewhere.
Fix the handle bottom
6
to the body of the mower
using pivot pins
13
. Ensure that the pivot covers
12
are fitted to the handle bottom
6
. (figure
A
)
Ensure that the handle stop
11
is fitted to the right
hand side when operating the mower (Elan 32)
Attach the handle top
1
with the bolts and the wing
nuts to the handle assembly.
Note: Ensure that the cable clips supplied are used
to fix the cable to the handle, as in figure
A
.
The blades may require adjustment - see Adjusting
the Blades.
Product Specification
Intended Use
Introduction
Delivered Items
Operating Controls
For Your Safety
WARNING! SWITCH OFF, REMOVE PLUG FROM
MAINS BEFORE ADJUSTING, CLEANING OR IF CABLE
IS CUT OR ENTANGLED.
THE BLADES CONTINUE TO ROTATE FOR A FEW SEC-
ONDS AFTER THE MACHINE IS SWITCHED OFF.
CAUTION - DO NOT TOUCH ROTATING BLADES.
Assembly
