QUALITY SERIES 2 PUMPS | OPERATION, INSTALLATION & WARRANTY INFORMATION
COMPLETE PUMP SWIMFLO 2
NO. COMPONENT PART NO. DESCRIPTION QTY
1 500-6411 Pump Lid Lock Ring 1
2a 110-5170 Series 2 PUMP UNION COMPLETE 50mm 2
2b 110-5171 Series 2 PUMP UNION COMPLETE 63mm 2
3 110-5123 Series 2 PUMP UNION O-RING 2
4 500-6410 Swimo2 PUMP LID 1
5 PUMP LID O-RING 1
6 500-6031 PUMP BASKET SUPERFLO 1
7 500-6326 Series 2 PUMP DIFFUSER O-RING 1
8 500-6053 PUMP DIFFUSER SCREW M4X25 3
9 500-6322 Series 2 PUMP DIFFUSER 1
10a 500-6331 Series 2 PUMP IMPELLER WITH INSERT 0,6kW 1
10b 500-6335 Series 2 PUMP IMPELLER WITH INSERT 0,75kW 1
10c 500-6402 Series 2 PUMP IMPELLER WITH INSERT 1,1kW 1
11 500-6165 Series 2 PUMP SHAFT SEAL 3/4” 1
12 500-6062 PUMP FLANGE O-RING 1
13 500-6321 Series 2 PUMP SEAL PLATE 1
14 500-6325 FLANGE BOLT SS M6X40 8
15a 500-1058 BARESHAFT MOTOR 0,6kW 230V 1
15b 500-2061 BARESHAFT MOTOR 0,75kW 230V 1
15c 500-3061 BARESHAFT MOTOR 1,1kW 230V 1
16 500-6327 FLANGE BOLT SS M8X30 4
17 500-6407 Swimo2 Pump Body 1
18 500-6398 Series 2 PUMP FOOT PIECE 1
19a 500-6213 WEDGE 0,6kW / 0,75kW 1
19b 500-6227 WEDGE 1,1kW 1
